Quick start ​

This is the ground-up guide: every command is written out, one at a time. At the end you have a hub with a panel, a second machine under an agent, a client on a laptop, and a Samba share mounted on it.

This walk installs server mode. Nothing on the network changes: every address the box has stays as it is, and no device is told to route through it. If you want the hub to hand out addresses and route your LAN, read Network modes first.

Four things this page does not do:

  • The panel is HTTP. Reach it over the LAN, or over an overlay.
  • The agent is Linux only, and it has no window. You join it from a terminal.
  • On Windows you run the client, and nothing else.
  • macOS runs none of the three packages.

What you need ​

  • A box running Linux with systemd, x86-64 or ARM64. A Pi, a TV box or an old laptop is enough.
  • A second Linux machine to manage. It is called studio here.
  • A laptop to run the client on. It is called laptop here.
  • All three on one network.

Install the hub and run setup ​

1. On the hub box, install the package:

bash
sudo apt install ./neutrino-hub_0.2.0_amd64.deb

Expect: apt reports the package installed, and nhub is on the path.

2. Start setup:

bash
sudo nhub setup

Expect: the terminal prints a URL carrying a one-time token and waits. On a machine with a browser, that browser opens on the URL. Pressing Enter instead runs the same six questions in the terminal.

The setup welcome screen, with the line about pouring a coffee and a "Set this box up" button

3. Screen 1, Language. Pick English or 简体中文. This is the language the panel is drawn in; the terminal stays English.

Expect: the counter above the question reads Config 1/6.

4. Screen 2, A password for the panel, a passphrase for the vault. Type a panel password, then a vault master passphrase.

Expect: both fields are accepted and Next lights up.

The secrets screen, with the panel password field above the vault master passphrase field

The passphrase cannot be recovered

The vault passphrase seals every credential this box will hold, and restoring a backup asks for it again. Nothing on the box can recover it for you.

Write it down somewhere off the box before you press Next. If it is lost, the way back is sudo nhub reset all and setting the box up from the beginning.

5. Screen 3, What is this machine for?. Choose Server.

Expect: the summary under the choice reads "Routes nothing; answers where it is reached."

The shape screen, with Server, Side gateway, Router and One-arm router offered as cards

6. Screen 4, Which ports?. Leave "Panel answers on port" at 8080.

Expect: the lead reads "No port is given a job. Every one of them keeps the address it has and answers to begin with; the panel's Network page narrows that afterwards."

The ports screen in server mode, listing this machine's ports and the panel port field

7. Screen 5, Going out through a proxy. Skip it.

Expect: Next stays live. Skipping is a real answer, and the Proxy page turns a proxy on later without redoing any of this.

The proxy screen, with the exit node links field and the SOCKS port field

8. Screen 6, Ready. Read the review and confirm.

Expect: the steps run one by one, ending on "This box is a gateway". Setup installs this box's own agent at the end, and asks you to choose no modules.

The review screen, listing shape, language, the ports answered on and the panel port

The done screen, headed "This box is a gateway", with an "Open the panel" button

Sign in ​

9. Open http://<hub>:8080 in a browser.

Expect: the sign-in page, headed by the Neutrino mark and "control panel", with one "Panel password" field and a "Sign in" button.

The sign-in page with the Neutrino mark, the panel password field and the Sign in button

10. Sign in with the panel password from screen 2.

Expect: the Dashboard. The rail on the left carries two groups, Hub with ten pages and Agent with six.

The Dashboard with live throughput, the exits in use and DNS queries

The sidebar, with the Hub group above the Agent group

The panel speaks HTTP. Reach it over the LAN, or over an overlay.

Add a second machine ​

11. Open Devices.

Expect: two sections, "Managed devices" and "Unmanaged devices". The hub's own machine is already managed, because setup enrolled it.

The Devices page, with home-hub under Managed devices and the LAN hosts below

12. Press "Add by link".

Expect: a notice carrying a neutrino://enroll/… link and a "Copy" button. The link lasts five minutes, and one is open at a time: making a new one cancels the old.

The enrollment notice with the neutrino://enroll link and a Copy button

13. On studio, install the agent:

bash
sudo apt install ./neutrino-agent_0.2.0_amd64.deb

Expect: the package installs and its service starts.

14. On studio, join the hub with the link you copied:

bash
sudo nagent connect 'neutrino://enroll/PLACEHOLDER_LINK'

Expect: the command returns, and within seconds studio appears under Managed devices with a live dot beside it.

TIP

The Devices drawer installs the agent for you over SSH, so a machine you can already reach never needs these two commands. See Devices and remote desktop.

Install the client ​

15. In the panel, open Clients and press "New client link".

Expect: a name field, with the placeholder "whose program this is, e.g. alice-laptop", and a "Create link" button.

The Clients page with the new client name field and the Create link button

16. Type laptop and press "Create link".

Expect: a notice reading "Paste this link into the client program for laptop." with the link and a Copy button. Five minutes again.

The client enrollment notice with the link for laptop and a Copy button

17. On laptop, install the client package, then open its window:

bash
nclient gui

Expect: a window headed "Neutrino client", with Status reading "Not connected" and the line "Paste the link from the hub's Clients page".

The client window before connecting, with the empty link field

No sudo here. The client runs as you, and nclient refuses to run as root.

18. Paste the link into the field and press "Connect".

Expect: Status reads "Connected" with the hub's version, a "Disconnect" button appears, and the Services section draws five panels: Web, Ports, AI, Files and Remote desktops.

The connected client window with the five service panels

The Clients page in the panel, with laptop listed as a Linux client and online

Publish a share and mount it ​

The Samba module runs under the agent on the machine that owns the disk. Here that machine is the hub box itself, which has an agent like any other.

19. In the panel, open Samba under the Agent group.

Expect: an "Enabled devices" picker, and the line "samba is on no machine yet".

20. Tick home-hub and press "Apply devices".

Expect: a consent dialog naming the machine, then the module installs and the page redraws with that machine's Samba panels.

21. Under "Users", press "Add user", name it alex, give it a password, then press "Apply users".

Expect: the row reads "created on apply" until the apply finishes, and the account exists afterwards.

22. Under "Shares", press "Add share", name it media, give it a directory, then press "Apply shares".

Expect: "Saves shares and reloads the server.", and media joins the list.

The Samba page with the media share and the alex user

23. Open Services.

Expect: four groups, Web, Ports, AI and Files, with media under Files, described "published by the samba module on home-hub".

The Services page with the four groups and the media share under Files

24. On laptop, in the client window, press "Config" in the Files panel.

Expect: a form with "Share username", "Share password" and "Mount path", the path already filled in as <home>/nas/media.

The client's Files panel with the share username, password and mount path fields

25. Type alex and its password, then press "Mount".

Expect: the button becomes "Unmount", and the share is readable at ~/nas/media.

The client's Files panel with media mounted and an Unmount button

Next ​

That is the whole path.
